Max. Working Pressure 11.5 bar (170psi)
Cover model table
‹
›
Increased efficiency and performance· The latest screw element technology.· A powerfull engine from a well-known and respected brand.- Work fast and stay productive· Robust mechanical engine and simple control panel for easy operation and service.· Large fuel tanks for uninterrupted operation overing a full work shift.· All components of our compressors are optimized for wear and tear; offering a long service life.
- Made to last wherever you need compressed air· Easy to service.· Solid, weatherproof enclosure.· Large cooling surfaces allow usage in high-temperature environments.· Compressor and engine are protected from dust and dirt particles through the heavy duty air filters and fuel filters.
Technical Specifications
Diesel Portable Air Compressor Part:
Single-stage screw compression, air-cooled, diesel engine driven, mobile unit for outdoor operation
Diesel Engine
Overall Dimensions and Weight
Main Configuration Description
Manufacturer:
Atlas Copco Airpower Belgium
Liuzhou Tech Machinery Co., Ltd.
Atlas Copco (Wuxi) Compressor Co., Ltd.
I. Unit Configuration and Origin
Core Technology Components
Screw Compressor Air Ends (Single-stage compression):
- The screw air end is manufactured and factory-tested by Atlas Copco (Wuxi) Compressor Co., Ltd.
Imported Components
- Coupling
- Control system
- Minimum pressure valve
- Second-stage screw air end
- Air inlet filter, oil filter, oil-air separator
- Flexible piping for high-temperature sections
- Inlet loading/unloading valve, regulating valve, solenoid valves
All the above components, including the control system and other parts, are manufactured by Atlas Copco Airpower Belgium or supplied by European OEM partners.
Locally Manufactured Components
- Diesel engine
- Gearbox
- Diesel fuel filter
- Sensors and associated wiring
- Air receiver and safety valves
- Various pipe fittings and castings
- Cooling fan and cooling radiator unit
- Enclosure panels, sound insulation materials and baffles
- Flexible pipes for normal temperature sections and fuel pipelines
- Trailer chassis and axle travel system, specially designed for Chinese road conditions
The diesel engine is manufactured by Dongfeng Cummins Engine Company. Other components are produced by Atlas Copco’s OEM suppliers in Wuxi.
Standard & Optional Systems
- FuelXpert™ Fuel Saving System (AC patented): Reduces overall fuel consumption by 10–15% compared to conventional units.
- Drilling Expert System (AC patented): Equipped with pressure control, flow control and dynamic air flow regulation. During the cuttings discharge phase, it can provide an additional 4 m³/min of airflow, increasing drilling efficiency by 30%, reducing fuel consumption by 15%, and improving machine residual value by 10%.
- Adjustable Minimum Pressure Valve (AC patented): Allows the minimum operating pressure to be reduced to 15 bar, extending the operating pressure range to 15–25 bar and significantly increasing application flexibility.
- Optional Oiltronix™ Electronic Oil Temperature Control System (AC patented): Extends the service life of the screw air end by more than 50%.
II. Main Control and Display Instruments
- Compressor operating pressure gauge
- Compressor load button
- Total running hours counter
- Alarm and fault indicator lights
- Start/stop buttons and control module
- Fuel tank level indicator
- Screw air end oil level sight glass
- Inlet air filter clogging indicator
III. Main Protection Devices and Functions
- Automatic Shutdown Protection:
- High compressor discharge temperature alarm indicator
- Low engine lubricating oil pressure alarm indicator
- High engine coolant temperature alarm indicator
- Low fuel level alarm indicator
IV. Supplied Documents and Accessories
- Operation and Maintenance Manual
- Spare Parts Manual
- Pressure Vessel and Safety Valve Certificates
- 50-hour Service Kit
Spare Parts
Have some special inquiry?
We offer fully customizable diesel portable air compressor solutions. Options include:
- Skid-mounted frames with DNV certification
- Explosion-proof configurations (Ex) with spark arrestors
- Explosion-proof configurations (Ex) with shutdown inlet valves
- Custom exterior finishes and nameplates
- Built-in aftercoolers
- Additional flow meters
- Enhanced soundproofing (acoustic insulation)
- Enhanced vibration-damping pads
- …and more upon request.
